Best 5 Projector Calculators For AV Professional

As an AV professional, you know that a good projector calculator is indispensable for designing and installing projection systems that guarantee maximum performance. A good projector calculator helps measure throw distance, screen size, brightness, and many other such considerations and ensures proper implementation.

A good projector calculator eliminates all chances of guesswork based on the projector model, room conditions, and viewing requirements. But which projector calculator best suits your needs? Hence, we bring you a comprehensive guide on the top 5 projector guide calculators available and used by AV professionals.

The guide will provide options based on accuracy, ease of use, feature set, and real-world integration into workflows for design and installation. We will point out what makes each tool unique and provide AV experts' perspectives on how they save time, minimize rework, and aid in securing new projects.

At the very beginning, let's put a little light on what a projector calculator is and why it is such an indispensable tool for AV system design.

What is a Projector Calculator?

A projector calculator is software (usually web-based) that assists you in establishing a projector and screen combination that will give you the best possible outcome. You will select parameters about your projector, screen, and room.

Once done, the calculator will output specifications like throw distance, screen size, brightness, lens shift and keystone and viewing angles . With that, let's take a refresher on these specifications for clearer and better understanding.

• Throw distance - The distance from the projector to the screen needed to create an image of a desired size.
• Screen size - Recommended screen dimensions for the specific throw distance and aspect ratio.
• Brightness (lumens) - Projector brightness required to view crystal-clear and vibrant images under the ambient light of the room.
• Lens shift and keystone - Degree of lens shifting and keystone correction required to align the image properly on the screen from the intended mounting position.
• Viewing angles - Recommended viewing distances and seating positions for comfortable viewing in consideration of screen size and eyesight of viewers.

Advanced projector calculators are capable of providing mounting diagrams, generating CAD drawings and parts lists, and verifying your projector selection to ensure that the model you select can indeed perform as required.

In the absence of a projector calculator, you will have to look manually for the throw ratio of a given projector, sort of imagine the relative positioning geometrically, and make reasonable estimations about brightness and image size. Although this could very well work in simple scenarios, it is very time-wasting and isn't error-proof for more complicated designs involving multiple projectors, difficult room layouts, and high ambient light.

A calculator witnesses all these difficult factors merged together in one smooth workflow, thus creatively enhancing your confidence in projector choices with considerable saving of time with every project. That's why a good, trustworthy projector calculator is a must-have tool for every professional AV designer and installer.

The Importance of Projector Calculators for AV Professionals

To professionals in the AV field, projector calculators aren’t simply nice-to-have tools; they are a requirement in ensuring their systems meet the expectations of their clients and do not end up being part of a costly rework process. Here are some reasons for why anyone working with projectors should use a calculator:

1. Accurate throw distances for reliable projector placement

The throw distance is one of the most important factors in any projector setup: the distance between the projector and the screen is needed for the desired size of the image. The image could either become too big or too small for the screen in the event of a miscalculation and adjustments to either the projector or screen would have to be made during installation.

An efficient projector calculator takes into consideration the exact throw ratio specifications of your particular projector model and gives you an accurate throw distance precise to it. Thus, you are assured your projector placement will produce an image of the size expected and vastly reduced chance of mid-project adjustments happening.

2. Appropriate brightness for the room conditions

Depending on the brightness of a projector, which is measured in lumens, the ambient light levels and screen size must be taken into account for fair reproduction of image quality. Fewer lumens, and the image becomes dim, washed out; more lumens, and you are wasting electricity and budget.

Advanced projector calculators will work on parameters like ambient light condition (light from windows, fixtures) and screen gain factor to suggest the ultimate brightness level for the selection of a projector that can still perform well in the actual environment rather than on paper.

3. Proper screen sizing and viewing angles

It is very pertinent to select the right screen size; it is uncomfortable for your view if it is too small and making one move his head from side to side to view the whole image if it is too big. A projector calculator will give you the best screen dimensions for your throw distance and viewer seating positions so that all in the room would enjoy comfortable viewing.

4. Faster, more accurate proposals and system designs

Those tools will help you in designing with accuracy and more quickly by automatizing complex calculations for projectors. Instead of getting down to the numbers, scribbling sketches, and staying up late, you simply have to enter the requirements, and in return, you will get the CAD drawings, parts lists, and even BOMs (bills of materials).

This speeds your entire design process and simultaneously avoids errors or omissions that are at times subject to change orders and loss of profit. The projector calculator allows you to give bigger and quicker responses to RFPs.

5. Clearer communication with clients and installers

Throw distance diagrams, room layout drawings, and projector/screen simulations are some of the clear visual aids provided by projector calculators. Those visual aids would help clients to understand your proposed setup, and install teams would get a clear and unambiguous reference on how to position equipment on-site.

By using a projector calculator to explain their designs, they eliminate the possibilities of misunderstanding with their clients and colleagues alike, ensuring that everyone is literally on the same page.

In essence, a good projector calculator is a must-have for any AV professional wishing to design a projection system that is accurate and high performing very fast and with fewer errors. It is the difference between guessing and getting precise figures, between lost time and productivity.

Speaking of which, let's jump into our very best projector calculator picks. These tools were selected based on their accuracy, ease of use, robust features, and reputation among AV industry professionals.

Best 5 Projector Calculators For AV Professional

1. XTEN-AV Projector Calculator

Overview:

When it comes to all-in-one projector calculators designed for AV system integrators, the XTEN-AV Projector Calculator is hard to beat. This powerful web-based tool goes beyond basic throw distance calculations to provide a comprehensive projector planning and proposal generation solution.

GET XTEN-AV 15 DAY FREE TRIAL CLICK BELOW

Key Features:

Massive projector database: XTEN-AV's calculator is hooked up to a library containing over 1.5 million items from thousands of AV brands. So you can specify your exact projector model, and the tool will calculate throw distances with actual manufacturer's specs for throw ratio, zoom range, lens shift, and so on. No guesswork or approximate ratios allowed.

Considerations for ambient light and screen gain: Taking ambient light into account depending on what you have for your screen, the XTEN-AV calculator advocates for the fixing of projector brightness requirements (in lumens). This "environment-aware" maxim will permit you to procure a projector that produces bright, vivid images in any given space.

Limitations related to lens shift and keystone: In calculating mounting, it ensures that any proposed mount position must be within the lens shift range and keystone correction limit of your projector to avoid deformations on the image.

Visual reports and CAD-related services: XTEN-AV can generate throw-distance diagrams, room layout drawings, and projector/screen simulations. Exporting these files in PDF or CAD format allows their inclusion directly into your proposals and design documents.

Automated parts lists and product validation: This calculator can automatically generate detailed BOMs with the proper accessories such as mounts, cabling, and screens. Its AI engine validates your parts list for compatibility issues, alerting you of missing or incompatible components.

Benefits for AV Pros:

Faster and better system designs: Using exact product specifications and considering real installation variables, XTEN-AV lets you come up with projector designs that are theoretically sound but also work out well at the installation site. That would save you time from playing with layouts and from calculator manipulation.

Installation errors and change orders: With hyper-detailed placement diagrams and AI-validated list of parts, installers can be guaranteed error-free directions and instructions to perform clean and fast installations with minimum changes and rework by the time of execution.

More professional, winning proposals: With the XTEN-AV generated visual reports, CAD drawings, and detailed BOM, your proposals will stand out from the rest. Clients would appreciate the detail and clarity of the presentation, making it that much easier to win the business.

Pricing:

XTEN-AV has a free projector calculator with core features that include throw distance, screen size, and brightness calculations.

User Reviews:

Projector calculator software from XTEN-AV has AV pros mesmerized. On other review platforms, such as Capterra and GetApp, users commend the accuracy of the product, its ability to perform various functions, plus all the time it has saved them. A few common comments are:

"Game changer for AV system design. The detailed drawings and BOMs have cut my proposal time in half." - Senior AV Engineer

"I love how it factors in the real-world environment and projector limits. No more guesswork or onsite surprises." - Freelance AV Consultant

"The AI-assisted parts lists and compatibility checks are a lifesaver. It's caught errors that would have cost me hours of rework." - Install Team Lead

A handful of users noted that the product database, while extensive, can sometimes lag behind for the very latest projector models. However, most found the manual product entry option a suitable workaround for those edge cases.

The Bottom Line:

When it comes to professional AV integrators and designers, XTEN-AV is the zenith of projector calculating software. Its repertiore of millions of products, ability to consider the environment in its calculations, and detailed export abilities and AI-assisted features make it a one-stop solution for projector planning.

The free-tier version of the calculator has more than enough functions for quick calculations, yet most professionals value the paid version as it saves them time through automation, allowing for fewer errors. So, if you want to actually speed up your projector workflows, XTEN-AV ought to be your primo option.

2. ProjectorCentral Projector Calculator

Overview:

Up till now, anybody looking for a projector has had really helpful information at his disposal with second-to-none reviews, buying guides, and the most popular projection calculator on the internet. The Projection Calculator Pro is a flexible and easy-to-use setup calculator that covers all the basics of projector setup.

Key Features:

Variable inputs: You give the desired screen size, throw distance, or projector model, and ProjectorCentral's calculator computes the other two variables accordingly. It simply lets one start planning from any variable one may know.

Projector specs: On selecting a projector model, the calculator would pull specs such as throw ratio, lens shift, zoom range, brightness, etc., from the exhaustive ProjectorCentral projector database. Hence, one may rest assured that the calculations are made on all accurate and current data.

Multiple screens: The calculator performs calculations for setups involving multiple screens so that more complex installations can be planned.

Downloadable reports: Download a more detailed PDF report about your projector setup, throw distance, screen size, brightness, etc., and share with clients or add to project proposals.

Benefits for AV Pros:

Flexibility: ProjectorCentral lets you start projector planning from any variable you already know-the screen size, throw distance, or projector model-and lets the calculator do the rest. This flexibility helps when you're being pressured by client constraints or existing room layouts.

Trustworthy calculations: ProjectorCentral is known to test projectors rigorously and collect data; so with the calculator, you know the specs are accurate and up to date, straight from the manufacturers.

Easy sharing and collaboration: The downloaded PDF reports will then allow you to share projector plans with your clients, colleagues, or installation partners. This makes the clear and detailed breakdowns serve as a binding sanctuary for all parties involved.

Pricing:

ProjectorCentral provides a free basic projection calculator with no sign-up required.

User Reviews:

Users appreciate ProjectorCentral's straightforward interface and flexibility of inputs. Being easy to use and producing reliable results explains why it is a favorite among AV pros and home theater enthusiasts.

User forum comments on ProjectorCentral praise the calculator for accuracy and the usefulness of downloadable reports:

"I've been using this calculator for years, and it's never steered me wrong. The results are spot-on, even in tricky rooms." - AV Installer

"The PDF reports are a huge time-saver. I can go from calculation to client presentation in minutes." - Home Theater Designer

The Bottom Line:

Projection Calculator Pro by ProjectorCentral is an easy-to-use and reliable tool that considers everything essential for a projector setup. Lacking some of the automation and AI features of XTEN-AV, it stands tall for immediate, correct calculations, and reports that you can share.

With flexibility on input and reputable specifications, it is suitable for both professional and DIY point-of-view.

3. Projector Screen Calculator (Projector Screen Store)

Overview:

The Projector Screen Calculator by Projector Screen Store is a really simple calculator to avoid any guesswork about finding the best screen size for your projector setup. It's a little more elementary than some of the other calculators in our tier list but is a very quick tool with which to lock down screen dimensions.

Key Features:

Screen size recommendation: Enter the projector model or the throw distance you desire, and the calculator will recommend screen sizes based on view dimension (16:9, 16:10, 4:3).

Viewing distance: It could also assist in determining appropriate viewing distance ranges for every kind of screen just to make sure that your audience will enjoy a comfortable and immersing experience.

Projector throws: If you are entering your desired screen size, the calculator will estimate the distance required by projectors of several common types (standard, short throw, ultra short throw).

Benefits for AV Pros:

In-a-Flash Screen-sizing: Whenever you need to get the screen sizing right for a projector or a room in a jiffy, this calculator will get you there with minimal fuss: just throw in either the throw distance or the projector model and get the size recommendations flashing back at you.

Comfortable Viewing: The tool enables you to calculate the ideal viewing range for every screen size, keeping setups comfortable and engaging fields-audience-end. Neck strain in the mush or sore eyes are things of the past.

Fewer Projector Choices: Having either pick screens at a given dimension or a range to work with and the throw calculator is going to help you narrow down your projector choices (standard throw, short throw, etc.).

Pricing:

The Projector Screen Calculator comes with free usage; no subscription or registration is needed.

User Reviews:

Users found the calculator to be wonderfully simple and fast to use. It is a good straightforward calculator to size screens for without any throws of complexity.

Customers give praise for the ease of use of the calculator on the Projector Screen Store:

"I needed to quickly spec a screen for a client's meeting room. This calculator gave me the perfect size in seconds." - AV Sales Rep

"Great tool for ensuring your audience is seated at the optimal distance. Takes the guesswork out of screen sizing." - Event Planner

However, some users consider the calculator a little lesser in features than some other bigger tools out there. It is perfect for screen sizing, but for more advanced projector planning, you'll most likely need other software.

The Bottom Line:

If you want a super-fast yet very bare-bones screen size calculator, then this calculator developed by Projector Screen Store is probably what you'll want to go with. It's quick and easy to use and can give you reliable size recommendations based on throw distance or projector models.

Also, there's no registration or charges for this tool, and for those times when you need that quick screen size estimate, this can certainly come in handy in your toolbox.

4. BenQ Projector Calculator

Overview:

BenQ, a world-leading projector manufacturer, offers free online calculator software near-product-related support. Though intended for BenQ projectors, the tooling can calculate throw distances, screen sizes, and so forth, with any brand of the projector.

Key Features:

Calculate Throw Distance And Screen Size: Input your projector model name or some desired image size, and the calculator will then give you the required throw distances or vice versa. You can also modify aspect ratios and zoom percentages to tune the results.

Projector & Screen Recommendations: Entering room dimensions and desired screen sizes will have the calculator suggest BenQ projector and screen models that will work to your criteria.

Mounting Position Guidance: From a visual standpoint, this tool charts out the vertical and horizontal offset of the projector from the screen relative to the guidelines for proper mounting placement.

Benefits for AV Pros:

Quick calculations for any projector: While the BenQ calculator is tailored for their own product line, you can use it with any projector brand by manually entering the throw ratio.

Good for BenQ projector pairing: If you often work with BenQ projectors, the calculator that can suggest projector and screen pairings suited to your room size will be much appreciated as it saves you loads of time.

Mounting instructions: Visual representation of projector offset from screen guides one through mounting positions so that the installations have proper clearance.

Pricing:

This BenQ Projector Calculator is available for use at no cost. No registration or subscriptions are required.

User Reviews:

BenQ customers appreciate that there's a free calculator that pertains to their projector purchases. The easy-to-understand interface and visual guides make the calculator usable for almost anyone, even for those with minimal familiarity with projectors.

On BenQ product forums, users rave about the convenience and mounting position guidance of the calculator.

"I love that I can just punch in my room size and the calculator spits out the perfect BenQ projector and screen for my needs."-Home Theater Enthusiast

"The offset visualization is so helpful for planning out the mounting position. It's a small thing, but it saves a lot of headaches during installation."-DIY Projector Installer

Users have expressed a wish that the calculator had more precise controls for certain variables such as zoom percentage and lens shift. However, these are fringe requests, and at a general run, the calculator does cover every major application.

The Bottom Line:

Particularly ambitiously with the calculator's recommendations of compatible projector and screen pairings, the BenQ Projector Calculator is a go-to for anybody with a BenQ projector looking for an easy brand-specific throw distance and screen size calculator. The calculator's projector & screen pairing recommendations are especially welcome from those trying to stay within the BenQ ecosystem.

And even if you don't use BenQ gear, the tool is still a blisteringly quick way to solve throw distance and screen size problems. The real icing on the cake is the visual guide for mounting location for clearance.

For advanced users, available options can feel limiting. But for the majority of setups, the calculator gets you through with fuss at any time and for Free!

5. Epson Projector Calculator

Overview:

Along with being one of the brand names recognized worldwide for projectors, Epson has a great online projector calculator within their product support toolkit. The Epson calculator asks for your room dimensions, screen size, and projector model and then computes throw distances, brightness recommendations, and others.

Key Features:

Throw Distance calculation: Insert the needed projector model screen size, then the calculator will suggest the correct throw distance range for adequate image-size playability.

Brightness Recommendations: Using your screen size and the general level of ambient light, the calculator suggests projector brightness (in lumens) within a range to get satisfactory image quality.

Detailed Projector Information: Given the model of an Epson projector, the calculator will eat color and light specs such as native resolution, contrast ratio, weight, and dimensions. It thus aids the user in keeping track of the finer points to see if the selected projector really meets all of the performance and installation criteria.

Lens shift and keystone specs: With the chosen projector model, the lens shift range and keystone correction range can be selected in the calculator. This is important to determine the mounting position so as to be able to align the projector properly with the screen.

Benefits for AV Pros:

Accurate calculations for Epson projectors: Since this calculator pulls specs directly from Epson's product database, you can rely on having the throw distance and brightness calculation done with the most accurate and up-to-date information for Epson models.

Helps to set optimum brightness for the environment: By considering your screen size and ambient light conditions, the calculator essentially helps you in selecting a projector with the right lumen output for your particular use case. This prevents a requirement for brightness specification from being under specified or over specified.

Offers key lens shift and keystone data: It is important to know about lens shift and keystone correction to install a projector accurately. The Epson calculator puts this information within your grasp for installation planning made easy.

Pricing:

The Epson Projector Calculator is provided at no charge and does not require registration or a subscription.

User Reviews:

With positive reviews various Epson users praise the projector calculator for being exceptionally accurate along with having much information applicable to the various projector models. For those who work extensively within the Epson environment, it is an essential tool for projector selection and setting up.

"The way it considers ambient light when recommending a brightness range is just awesome. It removes all of the guesswork involved in choosing the right projector for the room" - Corporate AV Manager

"Having everything all in one place, like detailed lens specs and keystone correction is a huge help with installations planning," - Freelance Projector Installer

Some users reported that the calculator would get "a bit slow" when loading projector data, but the general consensus is unanimously positive, with the majority feeling that the detail provided justifies the occasional waiting period.

The Bottom Line:

For Epson projector users, the Epson Projector Calculator is an essential tool for projector selection and setup. The Excel Calculator's throw distance and brightness calculations are truly accurate, while projector specs and lens shift and keystone data make it a one-stop shop for Epson projection planning.

Even if you don't exclusively use Epson projectors, the calculator is a valuable resource for ambient light awareness in brightness recommendations, as well as a plethora of projector information. Its intuitive interface coupled with the free price tag make it accessible at any skill level.

If you deal with Epson projectors frequently, then bookmarking the Epson Projector Calculator is just a no-brainer. And if Epson is not your main projector brand, this tool is well worth the extra effort, anyway.

Conclusion

Projector calculators are truly the best for the AV professional who wishes to expedite the processes of designing and installing projector systems. These tools save time, reduce errors, and ensure the best applications of a projector in an environment by automating complex calculations while providing information on projectors in detail.

This book has reviewed five of the best projector calculators around:

1. XTEN-AV Projector Calculator: Cloud-based, feature-rich solution for projector selection, room layout, and proposal generation. Suitable for AV integrators and designers.
2. ProjectorCentral Projection Calculator Pro: A calculator that is easy to use, flexible and allows for multi-screen support and downloadable PDF reports. This service can work for someone who is a low-level professional and for a DIYer.
3. Projection Screen Calculator (Projector Screen Store): A good, limited free calculator for projecting the ideal screen size based on the projectors throw distance or model.
4. BenQ Projector Calculator: The free, brand-specific calculator that suggests projector/screen pairs and comes with a visual mounting guide.
5. Epson Projector Calculator: A very capable, free calculator with detailed specs of projectors, brightness recommendations, and lens tilt/keystone specs for enthusiasts of Epson projectors.

Get answers to such questions as these before selecting a projector calculator: "Are there features like CAD exports and proposal generation that I need?" "Do I mostly work with one brand of projectors?" "Are factors like ambient light or screen gain that important in my calculations?"

Having the answers to all of these questions will allow you to narrow down the best calculator for your situation while remembering, you don't just have to choose one. Plenty of AV pros use several calculators so that they can double-check out work and get the most accurate calculations.

In any event, the right projector calculator is going to assist with crafting wonderful, high-performance projection systems while saving valuable time and eliminating many costly errors. These five calculators are the must-haves for your projector installation toolbox, no matter if you are just an amateur or an experienced AV Consultant.

Frequently Asked Questions

To ensure your any remaining queries are resolved by the end of this guide, we will be answering the common questions regarding projector calculators and projector setup below.

1. How do I calculate my projector throw ratio?

A projector's throw ratio is the distance to the screen divided by the width of the projected image. The throw ratio may be calculated in the formula way:

Throw Ratio = Throw Distance / Image Width

So for example, with a projector, the screen is 10 feet back and the image width is 6 feet. The throw ratio is:

Throw Ratio = 10 feet/ 6 feet = 1.67

Actually, the projector's spec sheets typically indicate the range of throw ratios for the lens (or lenses). You will use these throw ratio values with your intended screen size to find the throw distance that will fit your setup.

2. What is the perfect room size?

The factors that determine the best screen size for your room are:

Viewing distance: On the average, the width of the screen should approximately be one-third the maximum viewing distance. So, if you've got seats 12 feet from the screen, the screen should be 4 feet wide.

Throw distance: Based on the throw ratio of your projector and the zoom range, this decides the maximum size of an image that can be thrown at a certain distance. Employ a projector calculator to know the maximum size of a screen your projector can throw for the probable size of the room.

Ambient light: With immense ambient light in a room you will be compelled to choose a smaller screen to keep up with brightness and contrast. Going by the projector calculator, the optimum screen size can be obtained by plugging the luminosity output of your projector and surrounding light conditions.

3. What is the best way to determine the strength projector for my room?

Projection strength is expressed in lumens (ANSI lumens), and the lumens needed for your room are dependent on screen size, gain, and ambient light level. General hints for brightness are as follows:

• Small screens (up to 80 inches) in a dark room: 1,000-2,000 lumens.
• Medium screens (80-120 inches) in moderate light: 2,000-3,000 lumens.
• Large screens (120+ inches) in bright light: 3,000+ lumens.

Even more refined brightness will be calculated by a projector calculator that will consider your screen size, screen gain, and ambient light conditions, which will then be able to give you an ideal range of brightness that satisfies your criteria.

4. What makes short-throw projectors different from long-throw projectors?

To put it simply, the difference between short-throw and long-throw projectors lies in the distance needed to project an image of a given size:

By definition, a short throw projector has a throw ratio of less than 1, which means it may cast a large picture size from a short distance. For instance, a short throw projector with an actual throw ratio of 0.5 can throw a 6-foot-wide picture from a distance of only 3 feet.

Anything that is called "long throw" is with a throw ratio more than 1: therefore, long throw projectors need a compensatory increase in throw distance for the same size image. As per a long throw of 2.0 ratio, it will require 12 feet distance to throw a 6-foot-wide image.[citation needed]

Short throws suit small rooms and set-ups where the projector is required to be near the screen (like a projector just above the whiteboard). Long throws are well suited for bigger venues, such as auditoriums or lecture halls, where the projector can actually be some distance away from the screen.

5. How do I consider lens shift and keystone correction in placing a projector?

Lens shift and keystone correction will assist in fine-tuning image position and image geometry:

Lens Shift contains some movement of the lens either horizontally or vertically, the image being moved on the screen, so the projector is not physically moved. One would do so to align the image with the screen when installing the projector off-center.

Keystone correction makes the adjustment digitally, correcting the geometry of the image to compensate for a less than ideal projector placement. For example, if one had to tilt the projector upward to "hit" the screen, keystone correction would flatten the image so that it maintains a proper rectangular shape.

When going through your projector placement options, consider the range of lens shift and keystone your particular projector model offers. Use any available projector calculator (such as the Epson or BenQ ones mentioned above) to find the available Lens shift and Keystone values of your projector.

But remember, excessive keystone correction creates the edge of image quality, so whenever you can use lens shift to balance your projector placement, do so before keystone correction.
